F\textsubscript{1} = 5.0 N F\textsubscript{2} = 8.0 N
Added by Rachel S.
Close
Step 1
We have two forces, \( \vec{F}_1 \) and \( \vec{F}_2 \), with magnitudes of 5.0 N and 8.0 N, respectively. \( \vec{F}_1 \) makes an angle of 20° with the negative x-axis, and \( \vec{F}_2 \) makes an angle of 60° with the positive y-axis. Show more…
Show all steps
Your feedback will help us improve your experience
Mahipal Kumawat and 73 other Physics 103 educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
A disk of kg is attached to one end of a rope, as illustrated in the diagram. The other end is at a joint in the center of the platform. If the platform is rotating rapidly, the disk is on it and is released from rest, determine the time it takes for the disk to reach a sufficient speed to break the rope. The maximum tension that the rope can withstand is 100N, and the coefficient of friction between the disk and the platform is 0.1. Resp: t = 5.89
Adi S.
A hockey puck having a mass of 0.30 kg slides on the horizontal, frictionless surface of an ice rink. Two hockey sticks strike the puck simultaneously, exerting the forces on the puck. The force F1 has a magnitude of 5.0 N, and is directed at θ = 20° below the x-axis and the force F2 has a magnitude of 8.0 N and is directed at φ = 60° above the x-axis. Determine both the magnitude and the direction of the puck’s acceleration. Soln: Σ F_x = F_1x + F_2x = F_1 cos (-20°) + F_2 cos 60° = (5.0 N)(0.940) + (8.0 N)(0.500) = 8.7 N Σ F_y = F_1y + F_2y = F_1 sin (-20°) + F_2 sin 60° = (5.0 N)(-0.342) + (8.0 N)(0.866) = 5.2 N a_x = Σ F_x / m = 8.7 N / 0.30 kg = 29 m/s² a_y = Σ F_y / m = 5.2 N / 0.30 kg = 17 m/s² a = √((29 m/s²)² + (17 m/s²)²) = 34 m/s² θ = tan⁻¹ (a_y / a_x) = tan⁻¹ (17 / 29) = 30°
Maardava V.
Un tambor de 60 mm de radio se une a un disco de 120 mm de radio. El disco y el tambor tienen una masa total de 6 kg y un radio de giro combinado de 90 mm. Se ata una cuerda en la forma mostrada y se jala con una fuerza P de 20 N de magnitud. Si el disco rueda sin deslizarse, determine a) la aceleración angular del mismo y la aceleración de G y b) el valor mínimo del coeficiente de fricción estática compatible con este movimiento.
Madhur L.
