1. A 6.50-kg object is hung from the bottom end of a vertical spring fastened to an overhead beam. The object is set into vertical oscillations having a period of 2.30 s. Find the force constant of the spring. 2. A 65.0-g object connected to a spring with a force constant of 40.0 N/m oscillates with an amplitude of 8.00 cm on a frictionless, horizontal surface. (a) Find the total energy of the system. mJ (b) Find the speed of the object when its position is 1.20 cm. (Let 0 cm be the position of equilibrium.) m/s (c) Find the kinetic energy when its position is 3.00 cm. mJ (d) Find the potential energy when its position is 3.00 cm. mJ 3. A physical pendulum in the form of a planar object moves in simple harmonic motion with a frequency of 0.500 Hz. The pendulum has a mass of 2.00 kg, and the pivot is located 0.400 m from the center of mass. Determine the moment of inertia of the pendulum about the pivot point. 4. A pendulum with a length of 1.00 m is released from an initial angle of 14.5°. After 1 000 s, its amplitude has been reduced by friction to 3.50°. What is the value of b/2m?
Added by Tamara B.
Step 1
30 s and the mass of the object is 6.50 kg, we can use the formula for the period of a mass-spring system: \( T = 2\pi \sqrt{\frac{m}{k}} \), where T is the period, m is the mass, and k is the force constant of the spring. Show more…
Show all steps
Your feedback will help us improve your experience
Sri K and 73 other Physics 101 Mechanics educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
In Fig. 1, a block of mass m is attached to a wedge of mass M by a spring with spring constant k. The inclined frictionless surface of the wedge makes an angle α to the horizontal. The wedge is free to slide on a horizontal frictionless surface. (a) Find the Lagrangian for the system as a function of the x coordinate of the wedge and the length of the spring S. Write the equations of motion. (b) Find the natural frequency of vibration. 2. A simple pendulum of length 2l and mass 2m hangs is attached to a support of 3M mass which is driven horizontally with time as shown in Fig. 2. (a) Set up the Lagrangian for the system. (b) Find the equation of motion. (c) For small oscillations, find the normal modes and their frequencies. 3. Show that the geodesic on the surface of a right circular cylinder is a segment of a helix. 4. Consider a pendulum of mass m suspended by a massless spring with unextended length b and spring constant k. The pendulum's point of support rises vertically with constant acceleration a. (a) Use the Lagrange method to find the equations of motion. (b) Determine the Hamiltonian and Hamilton's equations of motion. (c) What is the period of small oscillations?
Adi S.
The length of a simple pendulum is 0.76 m and the mass of the particle (the "bob") at the end of the cable is 0.22 kg. The pendulum is pulled away from its equilibrium position by an angle of 8.70° and released from rest. Assume that friction can be neglected and that the resulting oscillatory motion is simple harmonic motion. (a) What is the angular frequency of the motion? rad/s (b) Using the position of the bob at its lowest point as the reference level, determine the total mechanical energy of the pendulum as it swings back and forth. J (c) What is the bob's speed as it passes through the lowest point of the swing? m/s A block is attached to a horizontal spring and oscillates back and forth on a frictionless horizontal surface at a frequency of 2.91 Hz. The amplitude of the motion is 5.60 10-2 m. At the point where the block has its maximum speed, it suddenly splits into two identical parts, only one part remaining attached to the spring. (a) What is the amplitude and the frequency of the simple harmonic motion that exists after the block splits? amplitude = m frequency = Hz
Timothy J.
An object of mass $m$ is hung from the base of an ideal spring that is suspended from the ceiling. The spring has a spring constant $k .$ The object is pulled down a distance $D$ from equilibrium and released. Later, the same system is set oscillating by pulling the object down a distance $2 D$ from equilibrium and then releasing it. (a) How do the period and frequency of oscillation change when the initial displacement is increased from $D$ to $2 D ?$ (b) How does the total energy of oscillation change when the initial displacement is increased from $D$ to $2 D ?$ Give the answer as a numerical ratio. (c) The mass-spring system is set into oscillation a third time. This time the object is pulled down a distance of $2 D$ and then given a push downward some more, so that it has an initial speed $v_{\mathrm{i}}$ downward. How do the period and frequency of oscillation compare to those you found in part (a)? (d) How does the total energy compare to when the object was released from rest at a displacement $2 D ?$
