Question

1. Determine the magnitude and direction of the resultant and perpendicular distance from Point A to the line of action of the resultant for a force and couple system below. Use (a) scalar formulation and (b) vector formulation to solve this problem. 18 in. 75 lb 50 lb C 10 in. 80 lb D 14 in. F 12 in. B E 100 in. lb A G 90 lb 16 in. 16 in. Figure for Question 1

          1.
Determine the magnitude and direction of the resultant and perpendicular distance from
Point A to the line of action of the resultant for a force and couple system below. Use (a)
scalar formulation and (b) vector formulation to solve this problem.
