10K a b 2K + 25V + V$_c$(t) 1µF 5V The switch has been in position a for a long time. At t=0 ms, the switch moves to position b. At t = 5 ms, it moves to position a. At t = 10 ms, it moves to position b. a) What is the RC time constant $\tau_b$ for the period from 0 ms to 5 ms? $\tau_b$ = b) What is the RC time constant $\tau_a$ for the period from 5 ms to 10 ms? $\tau_a$ = c) $V_c(t)$ = d) $V_c(5 \text{ ms})$ = e) $V_c(t)$ = f)$V_c(10 \text{ ms})$ = g) Sketch $V_c(t)$ for $0 \le t \le 10$ ms. A rough sketch is fine, but label the important times and voltages. for $0 \le t \le 5$ ms? for $5 \text{ ms} \le t \le 10 \text{ ms}$?

          10K
a b 2K
+
25V +
V$_c$(t) 1µF 5V
The switch has been in position a for a long time. At t=0 ms, the switch moves to
position b. At t = 5 ms, it moves to position a. At t = 10 ms, it moves to position b.
a) What is the RC time constant $\tau_b$ for the period from 0 ms to 5 ms? $\tau_b$ =
b) What is the RC time constant $\tau_a$ for the period from 5 ms to 10 ms? $\tau_a$ =
c) $V_c(t)$ =
d) $V_c(5 \text{ ms})$ =
e) $V_c(t)$ =
f)$V_c(10 \text{ ms})$ =
g) Sketch $V_c(t)$ for $0 \le t \le 10$ ms. A rough sketch is fine, but label the important times
and voltages.
for $0 \le t \le 5$ ms?
for $5 \text{ ms} \le t \le 10 \text{ ms}$?

10K
a b 2K
+
25V +
Vc(t) 1µF 5V
The switch has been in position a for a long time. At t=0 ms, the switch moves to
position b. At t = 5 ms, it moves to position a. At t = 10 ms, it moves to position b.
a) What is the RC time constant for the period from 0 ms to 5 ms? =
b) What is the RC time constant for the period from 5 ms to 10 ms? =
c) Vc(t) =
d) Vc(5 ms) =
e) Vc(t) =
f)Vc(10 ms) =
g) Sketch Vc(t) for 0 ≤ t ≤ 10 ms. A rough sketch is fine, but label the important times
and voltages.
for 0 ≤ t ≤ 5 ms?
for 5 ms≤ t ≤ 10 ms?
