Write a Matlab function which, when given the numerator and denominator of an open loop system transfer function, finds the poles of the closed loop system when unity negative feedback is applied. For instance, if the open loop system transfer function is G(s) = (s + 2) / (s^2 + 2s + 3) the inputs to your function will be num = [1 2] and den = [1 2 3]. The function should output -1.5000 + 1.6583i and -1.5000 - 1.6583i, which are the closed loop poles of the unity negative feedback system G(s) = G(s) / (1 + G(s))
Added by Brandon M.
Close
Step 1
Import the necessary modules. Show more…
Show all steps
Your feedback will help us improve your experience
Sri K and 70 other Physics 102 Electricity and Magnetism educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
Madhur L.
PROBLEM 3 Let a unity feedback control system have a loop transfer function: L(s) = 10(1+0.4s)/(s(1+2s)(1+0.24s+0.04s^2)) a) Draw the Bode plot b) Determine the gain margin and phase margin.
Adi S.
3- a. Use the Discretization concept to convert the given continuous state-space represented system to a discrete system. A = B = C = [2 0] b. For the system described above (in a), after discretization, determine the state feedback gain matrix K such that the closed-loop system will exhibit the deadbeat response to any initial x(0). Verify your answer. c. Study the controllability and observability of the given system. d. Find the homogeneous solution of the state-space represented system for: i. a unit step input and ii. x(0) = [0 2]T. e. Determine the state feedback gain vector K such that the closed loop poles of the system are located at z1 = 0.2 + j0.4, and z2 = 0.2 – j0.4.
