Part III Use the print below to answer the following questions. 1. What is the maximum overall length of the part? 2. What is the radius of the two holes? 3. What is the circumference of one of the holes? 4. What material is used to fabricate the part? 5. What is the complementary angle for the 63° angle? 6. Calculate the total length of weld needed if the vertical plates are welded on both sides. 7. Calculate the approximate area of the base plate. 8. What is the tolerance listed for 3-place decimals? 9. How many individual pieces are required to fabricate the part? 10. Determine the dimension or angle for the following: A B C D E F G H I J K L M N O 3.50 3.00 0.50 K .25 HRS plate typical F M C 153° 1.00 1.50 0.24 135° 3.00 E 27° 117° 63° O Ø.50 2 holes D J 1.00 1.50 B G 1.25 0.75 H L 2.50 A 4.00 N I General Tolerance .xx = +/- .050 .xxx = +/- .020 angular +/- 2° WRP Associates 0925-wrp 1:1

          Part III
Use the print below to answer the following questions.
1. What is the maximum overall length of the part?
2. What is the radius of the two holes?
3. What is the circumference of one of the holes?
4. What material is used to fabricate the part?
5. What is the complementary angle for the 63° angle?
6. Calculate the total length of weld needed if the vertical plates are welded on both sides.
7. Calculate the approximate area of the base plate.
8. What is the tolerance listed for 3-place decimals?
9. How many individual pieces are required to fabricate the part?
10. Determine the dimension or angle for the following:
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
3.50
3.00
0.50
K
.25 HRS plate typical
F
M
C
153°
1.00
1.50
0.24
135°
3.00
E
27°
117°
63°
O
Ø.50 2 holes
D
J
1.00
1.50
B
G
1.25
0.75
H
L
2.50
A
4.00
N
I
General Tolerance
.xx = +/- .050
.xxx = +/- .020
angular +/- 2°
WRP Associates
0925-wrp
1:1
