2. (3 points) Describe what a well-designed closed-loop control system would do to system output variable x(t)
Added by Sebastian N.
Close
Step 1
Step 1: Show more…
Show all steps
Your feedback will help us improve your experience
Sri K and 88 other Physics 102 Electricity and Magnetism educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
To simplify the problem now approximate the open-loop system with a lower order system as follows: G_{OL}(s) = frac{0.6(s+4)}{s(s+3.5)(s+1+8.5j)(s+1-8.5j)}. Part 1 has shown us that tuning parameters A and w for input v = Asin(wt) to achieve a desired behaviour of y(t) is not efficient, so we turn again to closed-loop control. A position sensor is purchased to measure y(t) accurately. First, use a controller C(s) = K such that the voltage supplied to the motor is v = K(r - y), where r is a reference signal. Q8-13. Produce the Bode Diagram for the closed-loop system with K = 70. On the Canvas quiz, you will be given different values of w. (Q8-10) Find the values of gain [dB] for the given values of w. [Canvas Input: two signed numbers - 5% tolerance allowed] (Q11-13) Find the values of phase [deg] for the given values of w. (The answer should be in degrees and in the range [0°, 360°)) [Canvas Input: two signed numbers - 5% tolerance allowed] Q14-16. For K = 50, plot r(t) = 10 sin (wt) and the corresponding y(t) for w = 0.75 [rad/sec], w = 7.5 [rad/sec], w = 75.0 [rad/sec] (two graphs on the same axes for each frequency). Capture enough time to show the steady-state response of y(t). Find the value of y(t) - r(t) when t is 100 s for w = 0.75, 7.5, 75.0 [rad/sec]. [Canvas Input: Three signed numbers - 5% tolerance allowed]
Sri K.
Adi S.
Consider a mechatronic system described by: y(t) = 1.5y(t−1) − 0.865y(t−2) + u(t−1) + 0.9u(t−2) + e(t) − 0.4e(t−1) where u(t) and y(t) are the input and output of the plant at the discrete-time instant, t, respectively. e(t) is a zero mean white noise sequence. (i) Express the above equation into a general form and give the polynomial A, B, and C. (ii) Obtain the desired closed-loop characteristic equation when poles at z = −0.6 ± j0.4. (iii) Design and describe a self-tuning control algorithm based on this system.
