2) Examine the two-bus power system provided in the diagram. Bus 1 serves as the slack bus with a set voltage of $V_1 = 1\angle 0^\circ$ per unit (pu). Bus 2 draws a load of 100 MW and 50 Mvar. The line connecting the buses has an impedance of $z_{12} = 0.12 + j0.16$ pu, on a base of 100 MVA. (80 points) Task: Calculate the voltage magnitude and phase angle at Bus 2 using the Newton-Raphson method. Instructions: Initial Guess:** Start with an initial estimate of $|V_2|^{(0)} = 1$ pu and $\delta_2^{(0)} = 0^\circ$. Conduct two iterations of the Newton-Raphson method to refine your estimate of the voltage at Bus 2. G1 $V_1 = 1.0\angle 0^\circ$ Bus 1 Bus 2 $z_{12} = 0.12 + j0.16$ pu S=100MW+j50Mvar

          2) Examine the two-bus power system provided in the diagram. Bus 1 serves as the slack bus with a set
voltage of $V_1 = 1\angle 0^\circ$ per unit (pu). Bus 2 draws a load of 100 MW and 50 Mvar. The line connecting the
buses has an impedance of $z_{12} = 0.12 + j0.16$ pu, on a base of 100 MVA. (80 points)
Task: Calculate the voltage magnitude and phase angle at Bus 2 using the Newton-Raphson method.
Instructions: Initial Guess:** Start with an initial estimate of $|V_2|^{(0)} = 1$ pu and $\delta_2^{(0)} = 0^\circ$. Conduct two
iterations of the Newton-Raphson method to refine your estimate of the voltage at Bus 2.
G1
$V_1 = 1.0\angle 0^\circ$
Bus 1
Bus 2
$z_{12} = 0.12 + j0.16$ pu
S=100MW+j50Mvar
