2) Transistor Biasing (10 points): For a given BJT, calculate the base current $I_B$ required to achieve a collector current of $I_C = 2 mA$ given a beta ($\beta$) value of 100. Then, design a voltage-divider bias circuit for this operating point. Assume $V_{CC} = 10V$, and minimize any loading effects (the setup should be stiff)
