00:01
In this question we have to draw the gate so for the a the gate will be here the input is a, c bar and d.
00:09
So this is what the and gate.
00:11
After that we are having one more gate.
00:14
Here the input is a, d and e bar.
00:19
And again we have the input as b and e bar.
00:25
And again we are having the input as b and c bar.
00:29
And here in the last we are having the input as three inputs that is a bar, c bar and e bar.
00:38
So what happen is every input go to a bigger gate.
00:42
So this is the bigger gate, this is the or gate.
00:46
And here we get d, this is the or gate.
00:49
So we will bring all the inputs here...
