20. The flow of river is \( 19 \mathrm{~m}^{3} / \mathrm{sec} \) produces a total brake power of \( 7000 \mathrm{~kW} \). It is proposed to install two turbines, one of which is twice the capacity of the other. The efficiency and specific speed of both units are assumed to be \( 80 \% \) and \( 61 \mathrm{rpm} \), respectively. Find the rotative speed of each unit if the measure of the head is \( 47 \mathrm{~m} \). A. \( 526 \mathrm{rpm}, 761 \mathrm{rpm} \) C. \( 110 \mathrm{rpm}, 155 \mathrm{rpm} \) B. \( 412 \mathrm{rpm}, 981 \mathrm{rpm} \) D. \( 348 \mathrm{rpm}, 616 \mathrm{rpm} \) ANS: C PTS: 1
Added by Benjamin M.
