Industry Print Exercise 10-2 Refer to the print PR 10-2 and answer the questions below:
1. The basic depth of this part is .715. What is the tolerance on that dimension?
2. What is the tolerance on the chamfer note?
3. In the auxiliary section view, there is a target size of .1577" What is the tolerance on that hole?
4. The central, smallest hole has a diameter of .118". What is the tolerance on that hole?
5. What is the maximum material condition of the largest body diameter of this part?
6. What is the angular tolerance for angles unless otherwise specified?
7. What is the tolerance for three-place decimal values unless otherwise specified?
Review questions based on previous units:
8. Are there any hidden lines shown on this drawing?
9. What is the name of this part?
10. What scale are the views on the original drawing?
11. Is Section B-B shown in alignment with other views or as a removed view?
12. What thread class is designated for the four small holes?
13. How many cutting-planes are indicated?
14. Does this drawing feature any auxiliary views?
15. Are there any reference dimensions on this print?
16. As dimensioned, does this drawing follow the cylinder rule?
