3 Assembly Language Programming
The final part of this assignment involves writing an assembly language program that reads an 8-bit value from the switch input and displays the value in hexadecimal format on the SSD units (and on the green LEDs). Start by working from the lights.s file. As in the tutorial, create .equ macros for the addresses of the PIO ports. Create one each for
leds, switches, hexa, and hexb. These may have changed with the addition of the new PIO ports.
To display a value on the seven-segment display, you need to issue a stbio instruction to the address from the Qsys layout. The value you write to the address is a 7-bit value which corresponds to each segment of the display. Recall that the SSD device uses negative-asserted true logic, so a 0 bit value activates an LED segment and a 1 bit value deactivates a segment. For example, if we wanted to make an 8 display, we would write 7 zeroes to the display: 0x00. To make only the top light segment display (segment 0), you would write all ones, except for the lowest bit (bit 0): 0xfe or 0x7e (the highest-order bit is ignored, since the SSD inputs are only seven-bit values).
Lookup Table: Rather than using the hardware circuitry that we created in Lab 2, we want to use a software lookup table to display the correct value on the SSD. To implement this, we will use a label, lut:, to mark the beginning of some constant data in our assembly language program.
To understand how a lookup table is implemented in assembly language, assume that we wanted to have a three-element array constant, a, with a[0]=5, a[1]=6, and a[2]=7. We would arrange this in our assembly language program like this:
.data
a:
.word 5
.word 6
.word 7
.end
This code is placed after the end of our assembly program, before the .end marker. The label a: marks the address of the first element of the array (index 0). Each element is stored in a four-byte word, so to compute a[2], we would use the base address stored in a, and add the size of each element (4 bytes) times the number of elements to skip over (2): a[2]=Mem[a+(4*2)]
Construct a 16-element array, one for each possible 4-bit combination of values to display on an SSD. The value of each array element should be a 32-bit word, with the lowest 7-bits containing the bit pattern to illuminate the correct segments for the corresponding 4-bit hexadecimal value. For example, the value of lut[8] should contain the 7-bit pattern (0x00) to illuminate all segments on the display.
Once you have completed your array, modify the main loop driver to write the 8-bit value from the switches to both HEXA and HEXB. You will have to read the 8-bit value into two registers, use these values to determine the offsets into the lookup table, load the pattern values from the LUT and write them each to the correct SSD, as well as the LEDs.
As an example, let's say that the value read from the switches is 11110001 (i.e. 0xf1). You need to move 0001 into one register and 1111 into another. Next, load the value at lut + 4*1 into a new register and lut + 4*15 into another. These registers should now contain the 7-bit patterns that can be written to the SSD using the stbio instruction.
