3. Water level in a flush tank is controlled by the mechanism shown in the figure associated with problem 3.50 in Katz' textbook. The condition shown, represents the 'tank full' condition and the water supply valve is closed. Assuming a negligible mass for the half sunken ball (of radius R = 0.10 m), calculate the vertical force on the valve at point B. (note that the arm is hinged at point A and $l_1$ = 0.12m and $l_2$ = 0.040m).

Name: 3. Water level in a flush tank is controlled by the mechanism shown in the figure associated with problem 3.50 in Katz' textbook. The condition shown, represents the 'tank full' condition and the water supply valve is closed. Assuming a negligible mass for the half sunken ball (of radius R = 0.10 m), calculate the vertical force on the valve at point B. (note that the arm is hinged at point A and l1 = 0.12m and l2 = 0.040m).
Uploaded: 2021-02-03T05:43:24-08:00
Duration: 4 min 49 s
Channel: Rashmi Sinha

          3. Water level in a flush tank is controlled by the mechanism shown in the figure associated with problem 3.50 in Katz' textbook. The condition shown, represents the 'tank full' condition and the water supply valve is closed. Assuming a negligible mass for the half sunken ball (of radius R = 0.10 m), calculate the vertical force on the valve at point B. (note that the arm is hinged at point A and $l_1$ = 0.12m and $l_2$ = 0.040m).

3. Water level in a flush tank is controlled by the mechanism shown in the figure associated with problem 3.50 in Katz' textbook. The condition shown, represents the 'tank full' condition and the water supply valve is closed. Assuming a negligible mass for the half sunken ball (of radius R = 0.10 m), calculate the vertical force on the valve at point B. (note that the arm is hinged at point A and l1 = 0.12m and l2 = 0.040m).

Added by Jeffrey T.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Rashmi Sinha

02/03/2021

Step 1

Since the ball is half submerged in water, it experiences a buoyant force equal to the weight of the water displaced by the submerged portion of the ball. The buoyant force can be calculated using the formula: Buoyant force = density of water * volume of Show more…
