32 ChemActivity 3: Electron Orbitals 4. Consider the incomplete orbital representation of O$_2$, below right. a. Identify which lobes are hybrid orbitals (identify the type) and which lobes are p orbitals. b. Use dotted lines to show any $\pi$ bonds. c. Use up or down arrows to show electron occupation of each hybrid orbital or bond. A double bond consists of one $\sigma$ overlap and one $\pi$ overlap. $\sigma$ bond (or vice versa) $\pi$ bond (or vice versa) Lewis Drawing of O$_2$ Orbital Drawing of O$_2$ 5. Consider the following orbital representation of HCCH (ethyne). Orbital Drawing of H-C$\equiv$C-H a. Answer the same three questions (a-c) from the previous exercise. b. Label each C-H $\sigma$ bond in the drawing above. c. What is the total number of $\sigma$ bonds found in ethyne? ... $\pi$ bonds? d. How many p orbitals are there on a single carbon of ethyne? e. How many hybrid orbitals are there on a single carbon of ethyne?
