Question

370) A shunt generator has a full-load current of 100A at 220V. Stray losses are 1000W and the shunt field current is 12A. The armature resistance including the brushes is 0.055 ohm. Calculate the efficiency of the machine. 360.) A shunt generator has an output of 6.6 kw at 100V. The Rsh is 25 ohms and the Ra is 0.05 ohm. If the overall efficiency is 89%, the combined core, friction, and windage losses is equal to?

Name: 370 a shunt generator has a full load current of 100a at 220v stray losses are 1000w and the shunt field current is 12a the armature resistance including the brushes is 0055 ohm calculate th 10302
Uploaded: 2023-06-19T08:27:04-08:00
Duration: 5 min 30 s
Channel: Adi S
Description: 370 a shunt generator has a full load current of 100a at 220v stray losses are 1000w and the shunt field current is 12a the armature resistance including the brushes is 0055 ohm calculate th 10302

          370) A shunt generator has a full-load current of 100A at 220V.
Stray losses are 1000W and the shunt field current is 12A. The
armature resistance including the brushes is 0.055 ohm. Calculate
the efficiency of the machine.
360.) A shunt generator has an output of 6.6 kw at 100V.
The Rsh is 25 ohms and the Ra is 0.05 ohm. If the overall
efficiency is 89%, the combined core, friction, and windage losses
is equal to?

Added by Jenna P.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Adi S

06/19/2023

Step 1

370) First, we need to calculate the input power to the generator: P_in = V_in x I_in P_in = 220V x 100A P_in = 22,000W Show more…

Show all steps
