5. A flow transmitter ranged 0 to 800 cc/min is tested by using a rotameter (visual flow indicator) in series as a reference standard. The fluid flow through a pipe is varied and both flow indications are recorded to test the transmitter against the rotameter. The results are shown below.
Input (%) Rotameter Reading (cc/min) Flow Transmitter Reading (cc/min)
0 0 0
25 200 180
50 400 360
75 600 540
100 800 720
a) Does this instrument have Zero, Span, or Linearity errors? Explain why or why not for each error type. (6 points)
b) What is the overall accuracy of this instrument currently? (2 points)
