5.33 A solid steel shaft tapers for a length of 1.5 m between end diameters for which one is twice the other. If the maximum shear stress and the angle of twist are limited to 60 MPa and 4° respectively under a torque of 10 kNm, determine the diameters. Take $G = 80 \text{ GPa}$.
