7. Applying the point rule at point a in the circuit below, (A) $I_1 + I_2 = -I_3$ (B) $I_1 + I_2 = I_3$ (C) $I_1 + I_3 = I_2$ (D) $I_1 = I_2 + I_3$ 8. Applying the loop rule to the loop a, b, c, d, a (A) $2V + 3\Omega I_1 - 3I_2 - 5V = 0$ (B) $2V - 3\Omega I_1 + 3\Omega I_2 - 5V = 0$ (C) $-2V - 3\Omega I_1 - 3\Omega I_2 + 5V = 0$

          7. Applying the point rule at point a in the circuit
below,
(A) $I_1 + I_2 = -I_3$
(B) $I_1 + I_2 = I_3$
(C) $I_1 + I_3 = I_2$
(D) $I_1 = I_2 + I_3$
8. Applying the loop rule to the loop a, b, c, d, a
(A) $2V + 3\Omega I_1 - 3I_2 - 5V = 0$
(B) $2V - 3\Omega I_1 + 3\Omega I_2 - 5V = 0$
(C) $-2V - 3\Omega I_1 - 3\Omega I_2 + 5V = 0$

7. Applying the point rule at point a in the circuit
below,
(A) I1 + I2 = -I3
(B) I1 + I2 = I3
(C) I1 + I3 = I2
(D) I1 = I2 + I3
8. Applying the loop rule to the loop a, b, c, d, a
(A) 2V + 3Ω I1 - 3I2 - 5V = 0
(B) 2V - 3Ω I1 + 3Ω I2 - 5V = 0
(C) -2V - 3Ω I1 - 3Ω I2 + 5V = 0
