This problem relates to tolerance stack-up using the absolute tolerance system, as explained in section 1-14. In the figure below, specified dimensions are as follows (all units in inches):
a = 1.7500 ± 0.001
b = 2.0000 ± 0.003
c = 3.2000 ± 0.005
p = 0.010
(a) If the gap, w, must be at least 0.015 in for the proper functioning of the assembly, what is the correct nominal dimension for d?
