9.3.10 Form an equivalent circuit for the transformer and primary in the network shown in Fig. P9.3.10, and use this circuit to find the current I2. 6Ω -j2 Ω j4 Ω 1:2 I1 I2 + 12/0° v + Vi V2 2Ω 24/0° V 3 Ω Ideal FIGURE P9.3.10
Added by Cynthia F.
Close
Step 1
The turns ratio is 1:2, so $a = \frac{N_1}{N_2} = \frac{1}{2}$. The impedance on the secondary side is $Z_2 = 2 + j4$. The reflected impedance on the primary side is $Z_1 = \frac{Z_2}{a^2} = \frac{2 + j4}{(1/2)^2} = 4(2 + j4) = 8 + j16$. Show more…
