Question

A 14 gauge copper wire of diameter 1.628 mm carries a current of 12.5 mA. (a) What is the potential difference across a 2.00 m length of the wire? (b) What would the potential difference in part (a) be if the wire were silver instead of copper, but all else were the same?

Name: a 14 gauge copper wire of diameter 1628 mm carries a current of 125 ma a what is the potential difference across a 200 m length of the wire b what would the potential difference in part a be 10224
Uploaded: 2022-07-01T17:06:46-08:00
Duration: 4 min 13 s
Channel: Suman K
Description: a 14 gauge copper wire of diameter 1628 mm carries a current of 125 ma a what is the potential difference across a 200 m length of the wire b what would the potential difference in part a be 10224

          A 14 gauge copper wire of diameter 1.628 mm carries a current of 12.5 mA. (a) What is the potential difference across a 2.00 m length of the wire? (b) What would the potential difference in part (a) be if the wire were silver instead of copper, but all else were the same?

Added by David S.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Suman K

07/01/2022

Step 1

68 x 10^-8 Ωm. The length of the wire is 2.00 m. The cross-sectional area of a 14 gauge wire can be found using the formula: Area = π x (diameter/2)^2 The diameter of the wire is 1.628 mm, which is equal to 0.001628 m. Plugging in the values, we get: Area = π Show more…

Show all steps
