A 3-phase, 6-pole induction motor runs on no-load at 1160 rpm. Determine the slip and frequency of rotor currents on no-load.
Added by Dennis B.
Step 1
Step 1: Calculate synchronous speed (Ns) using the formula Ns = (120 * f) / p Given f = 60 Hz and p = 6, Ns = (120 * 60) / 6 Ns = 1200 rpm Show more…
Show all steps
