A 52-V battery and resistor 1,R_(1),29-Omega and R_(2),94-Omega are connected in parallel. Calculate the equivalent resistance of the circuit.
R_(eq: )
2
Calculate the voltage drop through each resistor.
{:[v_(1)],[v_(2)]}
Calculate the current through each resistor.
I_(1):,A
I_(2),A
Hint: A diagram will be helpful.
1.A52-V battery and resistor1,R29-Q and R94- are connected in parallel.Calculate the equivalent resistance of the circuit Reai Calculate the voltage drop through each resistor V1: V V2: Calculate the current through each resistor 11: A 12: Hint: A diagram will be helpful.
