A beam is loaded and supported as shown in the figure below. Using the coordinate axes shown,
write equations for the shear force V, and bending moment M, for any section of the beam in
the interval 0.
A beam is loaded and supported as shown in the figure below.Using the coordinate axes shown write equations for the shear force V, and bending moment M, for any section of the beam in the interval0<x<10ft.
5001b
2001b/ft
x
A
B 2ft-
31
10ft
RA
RB
