00:01
For the given problem, we have been given that the value of d1 is 107 mm.
00:05
The value of d2 is given to be 750 kg per meter cube.
00:11
The value of ta is 1 .013 bar.
00:16
Similarly, the value of ta is 31 degree celsius.
00:20
The value of pt is 0 .7 bar.
00:24
The value of cda is 0 .82.
00:28
The value of cdf is 0 .7.
00:32
So, if we calculate the area, we have a1 to be equal to pi by 4, 0 .107 square.
00:38
This will come out to be 9 multiplied to 10 to the power minus 3 meter square.
00:42
Similarly, for the area 2, it will come out to be pi by 4, 5 .853 multiplied to 10 to the power minus 3 whole square.
00:50
So, this will come out to be 2 .7 multiplied to 10 to the power minus 5 meter square.
00:55
So, we can say that the value of rho a at 31 degree celsius will be equal to 1 .164 kilogram per meter cube.
01:06
So, if we find the discharge of air flow, let us suppose discharge of air flow is given as qa...
