Question

A construction site uses a hoist to raise and handle large objects as shown in the adjoining figure. A horizontal beam is capable of moving along the track. The following particulars are provided for the beam and cable Beam: Young's modulus 200 GPa, length = 3.1 m, second moment of area 3.4×10$^{-4}$ m$^4$ Cable: Young's modulus 204 GPa, length = 10 m, diameter = 12 cm Calculate the Stiffness of the beam $\boxed{}$ × 10$^6$N/m Stiffness of the cable $\boxed{}$ × 10$^6$ N/m Combines stiffness of beam and cable $\boxed{}$ × 10$^6$N/m when the hoist is used to raise a 850 kg machine, the natural frequency of the system is $\boxed{}$ Hz

          A construction site uses a hoist to raise and handle large objects as shown in the adjoining figure. A horizontal beam is capable of moving along the track. The following particulars are provided for the beam and cable
Beam:
Young's modulus 200 GPa, length = 3.1 m, second moment of area 3.4×10$^{-4}$ m$^4$
Cable:
Young's modulus 204 GPa, length = 10 m, diameter = 12 cm
Calculate the
Stiffness of the beam $\boxed{}$ × 10$^6$N/m
Stiffness of the cable $\boxed{}$ × 10$^6$ N/m
Combines stiffness of beam and cable $\boxed{}$ × 10$^6$N/m
when the hoist is used to raise a 850 kg machine, the natural frequency of the system is $\boxed{}$ Hz
