Question

A. Figure 4 shows a shaft carrying two sprockets for synchronous belt drives that are keyed to the shaft. Figure 4 (b) shows that a force F is transmitted from the shaft to the hub of the sprocket through a square key. The shaft has a diameter of 2.25 in and transmits a torque of 14 063 lb-in. The key has a square cross section, 0.50 in on a side, and a length of 1.75 in. Compute the force on the key and the shear stress caused by this force.

Name: a figure 4 shows a shaft carrying two sprockets for synchronous belt drives that are keyed to the shaft figure 4 b shows that a force f is transmitted from the shaft to the hub of the sprock 36154
Uploaded: 2024-05-14T04:54:15-08:00
Duration: 3 min 48 s
Channel: Adi S
Description: a figure 4 shows a shaft carrying two sprockets for synchronous belt drives that are keyed to the shaft figure 4 b shows that a force f is transmitted from the shaft to the hub of the sprock 36154

          A. Figure 4 shows a shaft carrying two sprockets for synchronous belt drives that are keyed to the
shaft.
Figure 4 (b) shows that a force F is transmitted from the shaft to the hub of the sprocket through a
square key. The shaft has a diameter of 2.25 in and transmits a torque of 14 063 lb-in. The key has a
square cross section, 0.50 in on a side, and a length of 1.75 in. Compute the force on the key and the
shear stress caused by this force.

a figure 4 shows a shaft carrying two sprockets for synchronous belt drives that are keyed to the shaft figure 4 b shows that a force f is transmitted from the shaft to the hub of the sprock 36154

Added by Rosario R.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Adi S

05/14/2024

Step 1

We know the torque transmitted by the shaft and the diameter of the shaft. The torque is related to the force and the radius of the shaft by the equation: $$T = F \cdot r$$ where T is the torque, F is the force, and r is the radius. Show more…

Show all steps
