A galvanic cell is constructed by placing a strip of nickel into a 1.0 M solution of nickel nitrate and a strip of iron into a 1.0 M solution of iron nitrate. The two metal strips are connected to a voltmeter by platinum wires and a salt bridge connects the solutions. See the diagram below. The temperature is 25 °C. The following standard reduction potentials apply: Fe3+(aq) + 3e? ? Fe(s) E° = ?0.040 V Ni2+(aq) + 2 e? ? Ni(s) E° = ?0.257 V Pt wire salt bridge Ni(s) Fe(s) Ni(NO3)2(aq) Fe(NO3)3(aq) Use the information above to answer the following three questions (A to C). A: What is E° for the cell? (Enter a value accurate to three significant figures). B: Which of the following statements is/are correct? (Select all that apply). - The nickel electrode is the cathode. - The Fe electrode increases in mass and the Ni electrode decreases in mass. - Electrons flow from the Fe electrode through the platinum wire towards the Ni electrode. - Positive ions in the salt bridge diffuse towards the nickel nitrate solution. - The iron electrode is the cathode. C: What is Ecell when the cell described above reaches equilibrium?

          A galvanic cell is constructed by placing a strip of nickel into a 1.0 M solution of nickel nitrate and a strip of iron into a 1.0 M solution of iron nitrate. The two metal strips are connected to a voltmeter by platinum wires and a salt bridge connects the solutions. See the diagram below. The temperature is 25 °C. The following standard reduction potentials apply:
Fe3+(aq) + 3e? ? Fe(s) E° = ?0.040 V
Ni2+(aq) + 2 e? ? Ni(s) E° = ?0.257 V

Pt wire
salt bridge
Ni(s)
Fe(s)
Ni(NO3)2(aq)
Fe(NO3)3(aq)

Use the information above to answer the following three questions (A to C).
A: What is E° for the cell? (Enter a value accurate to three significant figures).

B: Which of the following statements is/are correct? (Select all that apply).
- The nickel electrode is the cathode.
- The Fe electrode increases in mass and the Ni electrode decreases in mass.
- Electrons flow from the Fe electrode through the platinum wire towards the Ni electrode.
- Positive ions in the salt bridge diffuse towards the nickel nitrate solution.
- The iron electrode is the cathode.

C: What is Ecell when the cell described above reaches equilibrium?

Show more…

A galvanic cell is constructed by placing a strip of nickel into a 1.0 M solution of nickel nitrate and a strip of iron into a 1.0 M solution of iron nitrate. The two metal strips are connected to a voltmeter by platinum wires and a salt bridge connects the solutions. See the diagram below. The temperature is 25 °C. The following standard reduction potentials apply:
Fe3+(aq) + 3e? ? Fe(s) E° = ?0.040 V
Ni2+(aq) + 2 e? ? Ni(s) E° = ?0.257 V

Pt wire
salt bridge
Ni(s)
Fe(s)
Ni(NO3)2(aq)
Fe(NO3)3(aq)

Use the information above to answer the following three questions (A to C).
A: What is E° for the cell? (Enter a value accurate to three significant figures).

B: Which of the following statements is/are correct? (Select all that apply).
- The nickel electrode is the cathode.
- The Fe electrode increases in mass and the Ni electrode decreases in mass.
- Electrons flow from the Fe electrode through the platinum wire towards the Ni electrode.
- Positive ions in the salt bridge diffuse towards the nickel nitrate solution.
- The iron electrode is the cathode.

C: What is Ecell when the cell described above reaches equilibrium?

Added by Ashley C.

Chemistry: Structure and Properties

Nivaldo Tro 2nd Edition

Instant Answer

Solved by Expert Madhur L

03/20/2023

Step 1

Since the standard reduction potential for Fe is higher than that for Ni, Fe will be reduced and Ni will be oxidized. The half-reactions are: Fe³⁺(aq) + 3e⁻ → Fe(s) E° = -0.040 V (reduction) Ni(s) → Ni²⁺(aq) + 2e⁻ E° = -0.257 V (oxidation) Now, we need to Show more…

Show all steps

lock

Thanks for your feedback!

A galvanic cell is constructed by placing a strip of nickel into a 1.0 M solution of nickel nitrate and a strip of iron into a 1.0 M solution of iron nitrate. The two metal strips are connected to a voltmeter by platinum wires and a salt bridge connects the solutions. See the diagram below. The temperature is 25 °C. The following standard reduction potentials apply: Fe3+(aq) + 3e− ⇌ Fe(s) E° = −0.040 V Ni2+(aq) + 2 e− ⇌ Ni(s) E° = −0.257 V Pt wire salt bridge Ni(s) Fe(s) Ni(NO3)2(aq) Fe(NO3)3(aq) Use the information above to answer the following three questions (A to C). A: What is E° for the cell? (Enter a value accurate to three significant figures). B: Which of the following statements is/are correct? (Select all that apply). - The nickel electrode is the cathode. - The Fe electrode increases in mass and the Ni electrode decreases in mass. - Electrons flow from the Fe electrode through the platinum wire towards the Ni electrode. - Positive ions in the salt bridge diffuse towards the nickel nitrate solution. - The iron electrode is the cathode. C: What is Ecell when the cell described above reaches equilibrium?

Play audio

Feedback

Powered by NumerAI

Madhur L and 51 other subject Chemistry 101 educators are ready to help you.

Ask a new question

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Recommended Videos

Recommended Textbooks

Transcript

00:01 Hello students let's begin with this question this question is based upon the galvanic cell its composition is given in the question and reactions are also given.

00:09 The reactions are the galvanic cell is composed of the iron and nickel so this is the reaction and the e note for this reaction is minus 0 .040 volt and second one is nickel 2 positive plus 2 electron it will form nickel and its e note is also given in the question which is equal to minus 2 .0 .25 volt and let's solve the a part.

00:38 In the a part we have to find out the e knot of the cell.

00:42 So the formula used to find out the e note of the cell is e .0 cell is equals to the reduction potential of the reaction that is occurring at the cathode minus the reduction potential of the reaction that is occurring at the anode.

01:03 Now from the given reactions, this nickel, this nickel, this reaction is occurring at the cathode.

01:18 And this iron is occurring at the anode.

01:23 Now here the reduction potential of this nickel is 0 .25 minus minus 0 .0 .0.

01:34 So when we find out this, we get the e0 cell.

01:37 So e not of the cell should be e .0 cell is equal to minus 0 .27 volt.

01:46 Now in the next part, we have to answer the given statement.

01:51 Either the given statements are correct or not.

01:54 So the first part is asking about that the nickel is a the nickel is at the cathode.

02:05 The nickel electrode is at cathode.

02:14 The cathode is where the reduction occurs.

02:21 So in this case, n2 positive is reduced to.

02:26 Nickel.

02:28 So the first statement is the true.

02:32 This is true, true that nickel electrode is at cathode.

02:44 This is the correct statement.

02:47 Now the second statement is the iron electrode increases in mass and the nickel electrode decreases in mass.

02:55 So the answer of this part is this is incorrect.

02:59 Because this statement, this one is the first statement, this one is the second statement...
