Question

A GTAW operation is performed on low carbon steel, whose unit melting energy is 10.8 J/mm3. The welding voltage is 22 volts and the current is 149 amps. The heat transfer factor is 0.65 and the melting factor is 0.66. If filler metal wire of 3.9 mm diameter is added to the operation, the final weld bead is composed of 57% filler metal and the rest base metal. If the travel speed in the operation is 4 mm/sec, determine the feed rate (mm/sec, 1 decimal point) at which the filler wire must be supplied.

Name: a gtaw operation is performed on low carbon steel whose unit melting energy is 108 jmm3 the welding voltage is 22 volts and the current is 149 amps the heat transfer factor is 065 and the me 54328
Uploaded: 2022-04-28T12:39:31-08:00
Duration: 4 min 7 s
Channel: Shaiju T
Description: a gtaw operation is performed on low carbon steel whose unit melting energy is 108 jmm3 the welding voltage is 22 volts and the current is 149 amps the heat transfer factor is 065 and the me 54328

          A GTAW operation is performed on low carbon steel, whose unit melting energy is 10.8 J/mm3. The welding voltage is 22 volts and the current is 149 amps. The heat transfer factor is 0.65 and the melting factor is 0.66. If filler metal wire of 3.9 mm diameter is added to the operation, the final weld bead is composed of 57% filler metal and the rest base metal. If the travel speed in the operation is 4 mm/sec, determine the feed rate (mm/sec, 1 decimal point) at which the filler wire must be supplied.

Added by Charlotte A.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Shaiju T

04/28/2022

Step 1

Given: Voltage, V = 22 V Current, I = 149 A Heat transfer factor, η = 0.65 Heat input per second, \[ Q = V \times I \times \eta = 22 \times 149 \times 0.65 = 2131.7 \, \text{J/s} \] --- Show more…

Show all steps
