Question

A plane wall 6.0 cm thick generates heat internally at the rate of 0.3 MW/m³. One side of the wall is insulated, and the other side is exposed to an environment at 93ºC. The convection heat-transfer coefficient between the wall and the environment is 570 W/m² · ºC. The thermal conductivity of the wall is 21 W/m · ºC. Calculate the maximum temperature in the wall.

Name: a plane wall 60 cm thick generates heat internally at the rate of 03 mwm3 one side of the wall is insulated and the other side is exposed to an environment at 93oc the convection heat transf 04336
Uploaded: 2022-05-08T15:51:37-08:00
Duration: 1 min 51 s
Channel: Adriano Chikande
Description: a plane wall 60 cm thick generates heat internally at the rate of 03 mwm3 one side of the wall is insulated and the other side is exposed to an environment at 93oc the convection heat transf 04336

          A plane wall 6.0 cm thick generates heat internally at the rate of 0.3 MW/m³. One side of the wall is insulated, and the other side is exposed to an environment at 93ºC. The convection heat-transfer coefficient between the wall and the environment is 570 W/m² · ºC. The thermal conductivity of the wall is 21 W/m · ºC. Calculate the maximum temperature in the wall.

Added by Spencer F.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Adriano Chikande

05/08/2022

Step 1

3 MW/m^3 = 0.3 * 10^6 W/m^3 L = 0.06 m h = 570 W/m^2 * °C A = 1 m^2 T∞ = 93°C Substitute the values into the formula: 0.3 * 10^6 * 0.06 = 570 * 1 * (Tw - 93) 18,000 = 570(Tw - 93) Tw - 93 = 18,000 / 570 Tw - 93 = 31.58 Tw = 31.58 + 93 Tw = 124.58°C Show more…

Show all steps
