A robot arm using an open-loop control is experiencing overshoot and instability. Analyze two control system modifications that could reduce this instability and justify your response using stability principles
Added by Enrique S.
Step 1
- Goal: Reduce overshoot and improve stability by modifying the control approach and/or dynamics. Show more…
Show all steps
Your feedback will help us improve your experience
Adi S and 83 other Physics 101 Mechanics educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
Case Study: A human's ability to perform physical tasks is limited not by intellect but by physical strength. If, in an appropriate environment, a machine's mechanical power is closely integrated with a human arm's mechanical strength under the control of the human intellect, the resulting system will be superior to a loosely integrated combination of a human and a fully automated robot. Extenders are defined as a class of robot manipulators that extend the strength of the human arm while maintaining human control of the task. The defining characteristic of an extender is the transmission of both power and information signals. The extender is worn by the human; the physical contact between the extender and the human allows the direct transfer of mechanical power and information signals. Because of this unique interface, control of the extender trajectory can be accomplished without any type of joystick, keyboard, or master-slave system. The human provides a control system for the extender, while the extender actuators provide most of the strength necessary for the task. The human becomes a part of the extender and "feels" a scaled-down version of the load that the extender is carrying. The extender is distinguished from a conventional master-slave system; in that type of system, the human operator is either at a remote location or close to the slave manipulator but is not in direct physical contact with the slave in the sense of transfer of power. An extender is shown in Fig.1a. The block diagram of the system is shown in Fig.1b. Consider the proportional plus integral controller given as: Fig.1a R(s) 10 Y(s) Gc(s) s(0.5s + 1)(0.05s + 1) Human Input Output Actuator Fig.1b a. Determine the range of values of the controller gains Kp and Ki such that the closed-loop system is stable. Then select suitable values of controller constants for stable operation. b. Demonstrate the observable canonical state-space realization form of the system based on the selected controller values in a above with the aid of a block diagram. c. Applying the state-space theories to determine the state transition matrix and transfer matrix of this system. d. Draw the block diagram for the designed system of Fig.1b.
