(a) Three loads are connected in parallel across a 12.47 kV, three-phase, 50-Hz supply. Load 1: Inductive load absorbs 60 kW and 660 kVAr. Load 2: Capacitive load absorbs 240 kW at 0.8 power factor. Load 3: Resistive load absorbs 60 kW. (i) Determine the total complex power, power factor, and the supply current. (5 marks) (ii) A Y-connected capacitor bank is connected in parallel with the above loads. Determine the kVAr rating of the capacitor bank and the capacitance per phase (in µF) required to improve the overall power factor to 0.8 lagging. What is the new value of line current? (5 marks) (b) A 20-kVA, 440/220V, 50 Hz, single phase, two-winding transformer has the following test data: Open Circuit Test (OCT): 220V, 9.5A, 650W Short-circuit Test (SCT): 37.5V, 45.45A, 950W (i) Determine the rated currents in the high voltage and low voltage sides of the transformer. (2 marks) (ii) Determine the parameters of the approximate equivalent circuit of the transformer. (8 marks)
Added by Ismael W.
Close
Step 1
For Load 1: Apparent power (S1) = √(P1^2 + Q1^2) = √(60^2 + 660^2) = √(3600 + 435600) = √439200 = 662.6 kVA Power factor (pf1) = P1 / S1 = 60 / 662.6 = 0.0905 (lagging) For Load 2: Apparent power (S2) = P2 / pf2 = 240 / 0.8 = 300 kVA Power factor (pf2) = 0.8 Show more…
Show all steps
Your feedback will help us improve your experience
Adi S and 88 other Physics 102 Electricity and Magnetism educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
Sri K.
Figure 2 shows three loads connected in parallel across a 1000-V (RMS), 60-Hz single-phase source. Load 1 is an inductive load with a power factor of 0.28 lagging and a power rating of 125 kVA. Load 2 is a capacitive load with a power rating of 10 kW and a reactive power rating of 40 kVar. Load 3 is a resistive load with a power rating of 15 kW. Determine the total real power, reactive power, complex power, and power factor of the circuit. Problem 5 (20 Points) For the circuit in Problem 4, in order to improve the power factor to 0.8 lagging, a capacitor of negligible resistance is connected in parallel with the loads in Problem 4. Find the kVar rating of the capacitor and the capacitance in μF.
Adi S.
Problem (5): Three loads are connected in parallel across a 1400-V rms, 60 Hz single-phase supply as shown in the figure. Load 1: Inductive load, 125 kVA at a power factor of 0.28. Load 2: Capacitive load, 10 kW and 40 kVar. Load 3: Resistive load of 15 kW. a) Find the total kW, kVA, and the supply power factor. b) A capacitor is connected in parallel with the above loads to improve the power factor to 0.8 lagging. Determine the kVar rating of this capacitor.
