An orifice meter with an orifice diameter of 15 cm is inserted in a pipe with a diameter of 30 cm. The pressure difference measured by a mercury oil differential manometer on the two sides of the orifice meter gives a reading of (x = 50 cm) of mercury. Given the specific gravity of the oil (Soil = 0.9) and the coefficient of discharge of the meter is 0.64, calculate: i. pipe area (A1) ii. orifice area (A2) iii. area ratio (m*) iv. difference of pressure head (h) v. entrance velocity (v1) vi. theoretical flow rate (Q1) vii. actual flow rate (QActual)

Name: an orifice meter with orifice diameter 15 cm is inserted in a pipe of 30 cm diameter the pressure difference measured by a mercury oil differential manometer on the two sides of the orifice 27447
Uploaded: 2022-07-23T12:47:42-08:00
Duration: 4 min 40 s
Channel: Adi S
Description: an orifice meter with orifice diameter 15 cm is inserted in a pipe of 30 cm diameter the pressure difference measured by a mercury oil differential manometer on the two sides of the orifice 27447

          An orifice meter with an orifice diameter of 15 cm is inserted in a pipe with a diameter of 30 cm. The pressure difference measured by a mercury oil differential manometer on the two sides of the orifice meter gives a reading of (x = 50 cm) of mercury. Given the specific gravity of the oil (Soil = 0.9) and the coefficient of discharge of the meter is 0.64, calculate:

i. pipe area (A1)
ii. orifice area (A2)
iii. area ratio (m*)
iv. difference of pressure head (h)
v. entrance velocity (v1)
vi. theoretical flow rate (Q1)
vii. actual flow rate (QActual)
