Lab 1: Bias-Var Tradeoff & Poly Regression
The learning objective of this lab is to investigate the important bias-variance tradeoff in a linear regression setting under squared loss. This will be accomplished by running a small simulation study. The required tasks are stated in Section V.
Section II: Bias-Variance Tradeoff
Let (x1, y1), . . . , (xn, yn) be the training data and denote the trained model by f(x). Consider a single test case (x0,y0), which was not used to train f(x). The mean square error at test case (x0,y0) can be decomposed into three parts; i) variance of f(x0), ii) squared bias of f(x0), and iii) irreducible error variance Var(ε0).
The decomposition is stated below:
MSE(x0) = MSEf(x0) = E[(y0 − f(x0))^2] = Var(f(x0)) + (Ef(x0) − f(x0))^2 + Var(ε0)
Section III: True Model and Simulated Data
Assume X is not random taking on values in the interval [4, 20] and the true relationship between fixed X and response Y is:
y = f(x) + ε = (x − 5)(x − 12) + ε,
where ε is normally distributed with E(ε) = 0 and Var(ε0) = 20 .
Note that for test case (x0,y0), the statistical relation between x0 and y0 is y0 =f(x0)+ε.
The function true.f() defined in the code chunk below defines f(x) and is evaluated at x = 16.
true.f <- function(x) { f.out <- (x-5)*(x-12)
return(f.out)
} true.f(16)
The function sim.training() simulates a training dataset of size n = 20 based on our regression model. The training feature x is hard-coded and takes on equally spaced values over the interval [4, 20]. The only input of sim.training() is the feature test case x0.
The function returns the simulated dataset and the response for test case(s) x0.
sim.training <- function(x.test=c(16) ){
# Hard-coded sample size and standard deviation
n <- 20 sd.error <- 20
# Training x vector
x <- seq(4,20,length=n)
# Simulate training Y based on f(x) and normal error
y <- true.f(x)+rnorm(n,sd=sd.error) # Simulate test case
y.test <- true.f(x.test)+rnorm(length(x.test),sd=sd.error)
# Return a list of two entries: # 1) the dataframe data.train # 2) test respone vector y_0
return(list(data.train=data.frame(x=x,y=y), y.test=y.test))
}
To illustrate sim.training(), we simulate a training dataset using set.seed(1). Two test cases are chosen at x0 = 10,16. The following code chunk also plots the simulated data with the true relationship f(x) and chosen test cases. Make sure to run the entire code chunk at once.
# Simulate data
set.seed(1)
x.test <- c(10,16)
sim.data.train <- sim.training(x.test=x.test)
head(sim.data.train$data.train,4)
sim.data.train$y.test
# Plot simulated data
x.plot <- seq(4,20,by=.01)
x <- sim.data.train$data.train$x
y <- sim.data.train$data.train$y
plot(x,y,main="Simulated Data")
# Plot f(x)
lines(x.plot,true.f(x.plot),lwd=2,col="red")
# Plot test cases
y.test <- sim.data.train$y.test
abline(v=x.test,col="grey")
points(x.test,y.test,pch=20,cex=1.5,col="blue")
# Legend
legend("topleft",legend=c("f(x)","Test cases"),fill=c("red","blue"),cex=.5)
Section IV: Polynomial Regression and Tuning Parameter
Recall form lecture, the number of features (p) in a multiple linear regression model is a tuning parameter. This naturally extends to polynomial regression as stated in the below model:
y=β0 +β1x+β2x2 +···+βpxp +ε
In this case, the tuning parameter is the degree of our polynomial p. High degree polynomials can approximate any continuous differentiable function. However, too high of a degree can lead to overfitting and poor generalization.
To fit this model, use the the lm() function in conjunction with poly(). Technically we will utilize orthogonal polynomials which is not exactly the same as the polynomial regression model above. The function predict.test.case() defined in the code chunk below estimates y0 based on the pth degree trained polynomial, i.e., fp(x0). The inputs are; i) the degree of the polynomial degree, ii) the training data data, and iii) a vector test cases x.test.
predict.test.case <- function(degree, data, x.test) {
# Train model
model <- lm(y~poly(x,degree=degree),data=data)
# Predict test cases
y.test.hat <- predict(model,newdata=data.frame(x=x.test))
# Return y test case
return(y.test.hat)
}
To illustrate predict.test.case(), consider estimating y0 for inputs x0 = 10, 16, where the polynomial is trained using our simulated data sim.data.train. Notice that predict.test.case() can also be used for plotting.
x.plot <- seq(4,20,by=.01)
x.test <- c(10,16)
# Predict for degree=1
y.pred.1 <- predict.test.case(degree=1, data=sim.data.train$data.train, x.test=x.test)
y.plot.1 <- predict.test.case(degree=1, data=sim.data.train$data.train, x.test=x.plot)
# Predict for degree=2
y.pred.2 <- predict.test.case(degree=2, data=sim.data.train$data.train, x.test=x.test)
y.plot.2 <- predict.test.case(degree=2, data=sim.data.train$data.train, x.test=x.plot)
# Predict for degree=3
y.pred.3 <- predict.test.case(degree=3, data=sim.data.train$data.train, x.test=x.test)
y.plot.3 <- predict.test.case(degree=3, data=sim.data.train$data.train, x.test=x.plot)
# Plot simulated data
x <- sim.data.train$data.train$x
y <- sim.data.train$data.train$y
plot(x,y,main="Simulated Data")
abline(h=0,lty=2)
# Plot f(x)
lines(x.plot,true.f(x.plot),lwd=1.5,col="red")
# Plot the estimated curves
lines(x.plot,y.plot.1,lwd=1.5,col="green")
lines(x.plot,y.plot.2,lwd=1.5,col="purple")
lines(x.plot,y.plot.3,lwd=1.5,col="orange")
# Plot test cases
y.test <- sim.data.train$y.test
abline(v=x.test,col="grey")
points(x.test,y.test,pch=20,cex=1.5,col="blue")
# Plot estimated test cases
points(x.test,y.pred.1,pch=20,cex=1.5,col="green")
points(x.test,y.pred.2,pch=20,cex=1.5,col="purple")
points(x.test,y.pred.3,pch=20,cex=1.5,col="orange")
# Legend
legend("topleft",
legend=c("f(x)","Test Case","Degree 1","Degree 2","Degree 3"),
fill=c("red","blue","green","purple","orange"),
cex=.5)
The above code is clunky and can easily be refined. To clean up this process, the function poly.predict() defined below trains several polynomial models based on a vector of degrees and outputs the predicted response simultaneously. This function vectorizes predict.test.case(). The inputs are; i) a vector of degrees degree.vec, ii) a vector of x test points x.test, iii) a training dataset data. The output of poly.predict() is a matrix where the row corresponds to the respective test cases.
poly.predict <- function(degree.vec, data, x.test) {
# Vectorize predict.test.case()
pred <- sapply(degree.vec, predict.test.case, data=data, x.test=x.test)
# Name rows and columns
rownames(pred) <- paste("TestCase",1:length(x.test),sep="")
colnames(pred) <- paste("D",degree.vec,sep="")
return(pred)
}
# Test function poly.predict()
x.test <- c(10,16)
poly.predict(degree.vec=1:4, data=sim.data.train$data.train, x.test=x.test)
Section V: Student Tasks: (1) - (3)
Students will solve three major tasks in this lab.
Task 1
Simulate R=1000 training datasets and for each iteration (or each simulated dataset), store the predicted test cases corresponding to inputs x0 = 10, 16. For each simulated dataset, you must predict y0 using polynomial regression having degrees p = 1, 2, 3, 4, 5. You can easily solve this problem using a loop and calling on the two functions sim.training() and poly.predict(). Your final result will be three matrices. The first matrix mat.pred.1 is the collection of predicted test cases for each degree corresponding to input x0 = 10. Similarly, the matrix mat.pred.2 corresponds to x0 = 16. The first two matrices are dimension (5 × 1000). The third matrix y.test.mat is the collection of all test cases y0 for each simulated dataset. This matrix is dimension (2 × 1000). After completing this problem, display the first three columns of each matrix.
# Solution goes here -----------
Task 2
The second task is to estimate three different quantities based on the simulation from Task (1). For each polynomial degree (p = 1, 2, 3, 4, 5), use the matrices mat.pred.1, mat.pred.2 and y.test.mat to estimate:
1. The mean square error MSE(x0)
2. The variance Var(f(x0))
3. The squared bias (Ef(x0) − f(x0))^2
After solving this problem, display the 6 vectors of interest.
Notes:
1) When estimating the squared bias, students will use y.test.mat to estimate Ef(x0) but will also call the function true.f() for computing f(x0). Obviously in practice we never know the true relation f(x).
2) To estimate MSE(x0), you can slightly modify your loop from Task (1) or write a new program that computes (y0 − f(x0))^2 for all R = 1000 iterations. Then take the average of the resulting vectors.
# Solution goes here -----------
Task 3
The third task requires students to construct a plots showing MSE(x0), Var(f(x0)) and Bias2(f(x0)) as a function of the polynomial degree. There should be two graphics corresponding to the two test cases x0 = 10 and x0 = 16.
# Solution goes here -----------
