(c) A S B C Functional expression Truth Table: A B S C
Added by Jeremy W.
Close
Step 1
The circuit consists of two inputs, A and B, and two outputs, S and C. The top gate is an XOR gate, with inputs A and B, and output S. The bottom gate is an AND gate, with inputs A and B, and output C. Show more…
Show all steps
Your feedback will help us improve your experience
Manik Pulyani and 83 other AP CS educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
The Boolean expression for the truth table is $$ \begin{array}{llll} \hline \boldsymbol{A} & \boldsymbol{B} & \boldsymbol{C} & \boldsymbol{f} \\ \hline 0 & 0 & 0 & 0 \\ 0 & 0 & 1 & 0 \\ 0 & 1 & 0 & 0 \\ 0 & 1 & 1 & 1 \\ 1 & 0 & 0 & 0 \\ 1 & 0 & 1 & 0 \\ 1 & 1 & 0 & 1 \\ 1 & 1 & 1 & 0 \\ \hline \end{array} $$ (A) $B(A+C)(\bar{A}+\bar{C})$ (B) $\bar{B}(A+\bar{C})(\bar{A}+\bar{C})$ (C) $B(A+\bar{C})(\bar{A}+C)$ (D) $\bar{B}(A+C)(\bar{A}+\bar{C})$
