Question

Calculate the attenuation constant α in [Np/m] of a 1 [GHz] plane wave as it passes through a medium with a loss tangent of 0.05 if it is known that the medium is nonmagnetic and the wavelength at that frequency is 17.32 [cm].

Name: calculate the attenuation constant in npm of a 1 ghz plane wave as it passes through a medium with a loss tangent of 005 if it is known that the medium is nonmagnetic and the wavelength at t 19036
Uploaded: 2023-02-13T05:14:18-08:00
Duration: 2 min 11 s
Channel: Madhur L
Description: calculate the attenuation constant in npm of a 1 ghz plane wave as it passes through a medium with a loss tangent of 005 if it is known that the medium is nonmagnetic and the wavelength at t 19036

          Calculate the attenuation constant α in [Np/m] of a 1 [GHz] plane wave as it passes through
a medium with a loss tangent of 0.05 if it is known that the medium is nonmagnetic and the
wavelength at that frequency is 17.32 [cm].

Added by Omar F.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Madhur L

02/13/2023

Step 1

The loss angle δ can be calculated using the formula: δ = arctan(η) where η is the loss tangent. Given that the loss tangent η is 0.05, we can calculate the loss angle δ: δ = arctan(0.05) = 2.8624 degrees Show more…

Show all steps
