Calculate the peak voltage across each half of a center-tapped transformer used in a full wave rectifier that has an average output voltage of 120 V. Consider ideal diode. Express your answer in four decimal places.
Added by David H.
Step 1
636 * Vpeak where Vpeak is the peak voltage. We are given that Vavg = 120 V. We can rearrange the formula to solve for Vpeak: Vpeak = Vavg / 0.636 Substituting the given value: Vpeak = 120 V / 0.636 = 188.6792 V This is the peak voltage across the entire Show more…
Show all steps
Close
Your feedback will help us improve your experience
Aparna Shakti and 50 other Physics 102 Electricity and Magnetism educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
Example 5-1: The input voltage to a full-wave rectifier employing a center-tapped step-down transformer and two silicon diodes is 220 V rms. and the transformer has turns ratio n 0.125. Draw the rectifier circuit diagram when it is connected to a 100 Q load, and find the average value of the voltage across the load, the average power dissipated by the load, and the minimum PIV rating required for each diode.
Prabhu R.
Urvashi A.
A half-wave rectifier is needed to supply 15-V de to a load that draws an average current of $250 \mathrm{mA}$. The peak-to-peak ripple is required to be $0.2 \mathrm{V}$ or less. What is the minimum value allowed for the smoothing capacitance? If a full-wave rectifier is needed?
