Calculate the responsivity of a p-i-n photodiode at 1.3 μm and 1.55 μm if the quantum efficiency is 80%. (Planck constant h = 6.626x10^-34 m^2kg/s, the speed of light in vacuum c = 3x10^8 m/s, the elementary charge on the electron = 1.6x10^-19 C).
Added by Kevin S.
Step 1
First, we need to know the energy of a photon with a wavelength of 1.3 μm and 1.55 μm. We can use the formula: E = hc/λ where h is Planck's constant, c is the speed of light, and λ is the wavelength. For 1.3 μm: E = (6.626x10^-34 J.s)(3x10^8 m/s)/(1.3x10^-6 m) Show more…
Show all steps
