          Question 8
Figure Q8 shows a section of a steel component on which a Delta strain gauge
rosette has been attached. The Young's modulus (E) for the material is 200 GPa
and the shear modulus (G) is 80 GPa. The strain gauge readings from the rosette
are:
$\epsilon_a = 40 \mu$, $\epsilon_b = 980 \mu$, $\epsilon_c = 330 \mu$,
(a) Determine the principal strains and their orientations relative to the x direction,
either by calculation or by a Mohr's strain circle construction, you are NOT
required to do both.
(b) Hence determine the principal stresses.
(12 marks)
(8 marks)
Z
94
60°
00660
a
x
