Consider an n-channel MOSFET with W = 15 μm, L = 2 μm, and COX = 6.9×10^-8 F/cm^2. Assume that the drain current in the linear region for VDS = 0.10 V is IDS = 35 μA at VGS = 1.5 V and IDS = 75 μA at VGS = 2.5 V. Determine the inversion carrier mobility and the threshold voltage from experimental results.
