Name: 5. Consider the behavior of the heat equation in heterogeneous materials with varying thermal conductivities. Investigate how spatial variations in thermal properties affect the propagation and distribution of heat. Discuss how one might modify the heat equation to accommodate varying conductivities or heat sources in different regions.
Uploaded: 2023-07-14T09:36:40-08:00
Duration: 4 min 42 s
Channel: Madhur L
Description: 5. Consider the behavior of the heat equation in heterogeneous materials with varying thermal conductivities. Investigate how spatial variations in thermal properties affect the propagation and distribution of heat. Discuss how one might modify the heat equation to accommodate varying conductivities or heat sources in different regions.

5. Consider the behavior of the heat equation in heterogeneous materials with varying thermal conductivities. Investigate how spatial variations in thermal properties affect the propagation and distribution of heat. Discuss how one might modify the heat equation to accommodate varying conductivities or heat sources in different regions.

Transcript

00:01 Hello students, the three methods of heat transfer are one is conduction, second one is convection and the third one is radiation.

00:24 In conduction a process of transmission of heat in solids without the actual movement of particles takes place.

00:38 No actual movement will be there.

00:45 Then in convection the process of transmission of heat in fluid with the actual movement of particles takes place.

00:53 So there will be actual move of particles.

01:00 Then in radiation the transmission of heat without any medium.

01:10 Example for conduction is electric burner of stove and bottom of the pan.

01:17 So there will be no actual movement of the particles takes place but the heat transfer takes place from burner to pan.

01:25 Then for convection in forced air furnace and the weather system.

01:32 Here movement of particles takes place that is air particles movement takes place.

01:39 Then in radiation that is warming of earth by the sun.

01:42 There will be no medium between earth and the sun but heat from sun transfers to earth.

01:50 Next we need to give the equation for the given condition.

01:54 First one conductive heat transfer for that heat due to conduction is equal to k a delta t divided by delta x where delta x is the thickness delta t is temperature difference a is the surface area k is the constant of proportionality...
