Consider the slider-crank mechanism shown. Following the steps listed, analytically determine the linear displacement of the piston as the 44 mm crank is rotated 120° clockwise from its current position.
ww 66
44 mm
piston
30°
crank
Draw the kinematic diagram of the final configuration after the crank is rotated 120° clockwise from the initial configuration. Again, use the same rules and identities as previously to determine the position of the piston in this configuration. Remember to show your detailed work. Calculate the displacement of the piston.
