DC-Circuit I
Name: \( \qquad \) Linesse Partner(s): \( \qquad \) Itzel + Eduardo Date: \( 4 \mid 29 / 25 \)
Pre-lab Questions
1) Write Ohm's Law in your lab report making sure to define all terms in the equation. \( V=I R \quad V \) equals voltage, I equals autrent, anel \( R \) equals resistance,
2) Find and write down the rule for how resistors add in series wiring arrangements.
3) Find and write down the rule for how resistors add in parallel wiring arrangements.
4) Predict what the values of resistors with the following bands of color are using the color decoding rules and examples provided on Pages 1-2:
\begin{tabular}{|c|c|c|c|c|c|}
\hline 1 & Brown & Black & Brown & Gold & \( (100 \pm 5) \Omega \) \\
\hline 2 & Green & Blue & Violet & Silver & \( (560 \pm 56) \mathrm{M} \Omega \) \\
\hline
\end{tabular}
