Determine RRRV for (a) Grounded fault (b) Ungrounded fault if in a short circuit test on a 220 kV, three phase circuit breaker having earthed neutral has the following results Fault p.f = 0.4, recovery voltage = 0.9 of full line value Breaking current is symmetrical and the restriking transient of natural frequency 18 kHz.
