Draw floor plan of the Departmental conference room.
(b) Find the sensible and latent heat load of the room.
Hints for Q.1:
CALCULATION SHEET
Space used for office : 27 m 17 4 1836
Effective Room Sensible Heat
S/No Type of load Load (W)
1. Sensible solar heat gain through window glass W
2. Solar transmission gain- walls and roof W
3. Transmission gain- Others W
4. Internal heat gain W
Room Sensible Heat Load Calculation
1. Sensible Solar Heat gain through Wind
Item Area (m2) Solar heat gain / m2 (W) Load (W)
East glass - - -
West glass m2 W / m2 W
North glass m2 W / m2 W
South glass m2 W / m2 W
Sky light - - -
Total W
2. Solar transmission gain through- walls and roof
Item Area, A (m2) Conversion/multiplication factor, U W / (K / m2) Equivalent Temperature Difference, ΔT (Co) Load, UAΔT (W)
East glass - - - -
West glass m2 W / K / m2 Co W
North glass m2 W / K / m2 Co W
South glass m2 W / K / m2 Co W
Sky light - - - -
Total W
3. Transmission gain- Others
Item Area (m2) Temperature difference, ΔT (Co) Conversion/ Multiplication factor, U W / (K / m2) Load UAΔT (W)
Doors - - - -
All glass m2 Co W / K / m2 W
Partition m2 Co W / m2 W
Floor m2 Co W / m2 W
Infiltrated load Co 20.4 cmm BPF ΔT = W
Ventilated load Co W
Total W
