Schematic diagrams of improved conventional CAES system CAES system with gas turbine cycle Draw a schematic representation of CAES system with gas turbine cycle 1 15 and 24. Electricity, 2. Motor, 3 and 16.Air, 4 and 17. Filter, 5 and 18. Compressor, 6. Intercooler, 7 8 11 And 25. Valve, 9. Underground Cavern, 10.Compressed Air, 12. Recuperator, 13 and 21 Turbine, 14 and 23 Generator, 19. Combustor, 20. Fuel, 22. Exhaust Draw this cycle on T-S diagram

          Schematic diagrams of improved conventional CAES system
CAES system with
gas turbine cycle
Draw a schematic
representation of CAES
system with gas turbine cycle
1 15 and 24. Electricity, 2. Motor, 3 and 16.Air, 4 and 17. Filter, 5 and 18. Compressor, 6. Intercooler, 7 8
11 And 25. Valve, 9. Underground Cavern, 10.Compressed Air, 12. Recuperator, 13 and 21 Turbine, 14
and 23 Generator, 19. Combustor, 20. Fuel, 22. Exhaust
