Exercise 8.02 Calculate the apparent power, the reactive power, the true power and the power factor in the circuit below. Given: v = 120sin(377t + \frac{\pi}{9}) (V) i = 36.0sin(377t) (A) S = = = \theta = pf = P = = = Q = = =
Added by Katherine D.
Close
Step 1
The complex power (S) is given by the product of the voltage (V) and the conjugate of the current (I*). S = V * I* To calculate the conjugate of a complex number, we need to change the sign of the imaginary part. Given: V = 120∠(377°/9) V and I = 36.0∠377° Show more…
Show all steps
Your feedback will help us improve your experience
Geeta Yadav and 57 other Physics 102 Electricity and Magnetism educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
Voltage and current in an ac circuit are given by $$ v=200 \sin 377 t \quad i=8 \sin (377 t-\pi / 6) $$ Determine true power, reactive power and apparent power drawn by the circuit.
Single-Phase AC Circuits
Behaviour of a Pure Resistor in an ac Circuit
Calculate the apparent power, power factor, and reactive power associated with a load if it draws complex power S equal to:a. 1 + j0.5 kVAb. 400 VAc. 150 angle -21 degrees VAd. 75 angle 25 degrees VAPlease show work
Madhur L.
If an admittance of a circuit is $(8+j 6) \mho$ and the circuit current is $2 \angle 30^{\circ} \mathrm{A}$, find the pf of the circuit. Also, calculate the apparent power in the circuit.
