4. For the circuit on Figure P8.33 at the bottom of page 300 of the Nilsson Riedel textbook, a) determine the initial conditions for the capacitor voltage and the inductor current that are applicable when switch 1 has been open for a long time and closes at time t=0 and switch 2 has been closed for a long time and opens at time t=0. b) Using the transformed circuit that incorporates impedances, Laplace Transforms, and initial conditions, obtain the complete solution for the capacitor current using a current reference orientation pointing downwards.
Figure P8.29
i(t) = 350 mH
60mA
200nF
R
4. For the circuit on Figure P8.33 at the bottom of page 300 of the Nilsson Riedel textbook. a) determine the initial conditions for the capacitor voltage and the inductor current that are applicable when switch 1 has been open for a long time and closes at time t = 0 and switch 2 has been closed for a long time and opens at time t = 0 . b) Using the transformed circuit that incorporates impedances, Laplace Transforms, and initial conditions, obtain the complete solution for the capacitor current using a current reference orientation pointing downwards.
