Figure Q6 shows a simplified view of a dry sump oil lubrication
system, as may be found on some motor bikes and in racing cars.
Describe the key differences between dry and wet sump
lubrication systems. Identify the additional components that are
required for dry sump lubrication systems and explain the function
that each component performs as the oil passes through it.
Figure Q6. Visual model of dry sump oil lubrication system
